Flat head tapping screw, type C with hexagon socket

Article No. 420914219

ISO 14585 steel zinc plated flat head TX shape C SCR-PANHD-ISO14585-C-TX20-(A2K)-4,2X19

€3.82 inc. VAT price per 100 PCS

AVAILABLE

Qty:

+ -

ISO 14585, galvanised steel, blue coated, shape C (pointed)

ISO 14585, galvanised steel, blue coated, shape C (pointed)

Products specifications

Nominal diameter (d₁)	4.2 mm
Length (l₁)	19 mm
Head diameter (d_k)	8 mm
Head height (k₁)	3.1 mm
Material	Steel
Surface	Zinc plated
RoHS-compliant	Yes
Form	C
Internal drive	TX20
ISO	14585
Head type	Flat head
Thread type	Self-tapping screw thread
Declaration of performance (EU-CPR)	No

Würth Catalogue(2)

Catalogue page as PDF 1
