Hexagon Socket Head Cap Screw with metric fine pitch thread

Article No. 008010535

ISO 12474 / DIN 912 steel 10.9, plain, fine thread SCR-ISO12474-10.9-IH10-M10X1,25X35

€0.45 inc. VAT price per 1 PCS

AVAILABLE

Packaging Unit *

Qty:

+ -

DIN 912, steel 10.9, plain

Notice

DIN 912 has been withdrawn and replaced by ISO 4762 and ISO 12474. There is some similarity (nominal range changed | standard thread defined in ISO 4762, fine thread moved to ISO 12474).

Specification
Technical Information
Documents

DIN 912, steel 10.9, plain

Notice

DIN 912 has been withdrawn and replaced by ISO 4762 and ISO 12474. There is some similarity (nominal range changed | standard thread defined in ISO 4762, fine thread moved to ISO 12474).

Products specifications

Thread type x nominal diameter x pitch (d₁)	M10 x 1.25
Length (l₁)	35 mm
Head diameter (d_k)	16 mm
Head height (k₁)	10 mm
Standards	ISO 12474
Material	Steel
Property class	10.9
Surface	Plain
RoHS-compliant	Yes
Head type	Socket head
Drive type	Hexagon socket
Internal drive (s₁)	IH8
Thread type	Metric thread
Pitch	1.25 mm
Thread format	Fine pitch thread
Product class	A
