Ratchet combination wrench, metric, straight

Article No. 071425121

Ratchet combination wrench, metric, straight RTCHCOMBIWRNCH-WS21 ZEBRA

€36.76 inc. VAT price per 1 PCS

AVAILABLE

Packaging Unit *

Qty:

+ -

Drive: Modified POWERDRIV bi-hexagon ring end, finely toothed, 72 teeth
Standard: max. torque according to DIN 899
Geometry: Straight ring end, jaw angle 15°
Loosen bolts with the open end and tighten with the ratchet mechanism of the ring end
Ultra slim ring end for working in tight spaces, 5° angle of rotation, precision-manufactured ring core for smooth, secure movement
Material: Chromium-vanadium steel
Basic body surface: chrome-plated, matt satin finish

Notice

This special tool may only be subjected to the maximum torque. For this reason, the wrenches are only suitable for loosening bolts to a limited extent.

Specification
Technical Information
Documents

Drive: Modified POWERDRIV bi-hexagon ring end, finely toothed, 72 teeth
Standard: max. torque according to DIN 899
Geometry: Straight ring end, jaw angle 15°
Loosen bolts with the open end and tighten with the ratchet mechanism of the ring end
Ultra slim ring end for working in tight spaces, 5° angle of rotation, precision-manufactured ring core for smooth, secure movement
Material: Chromium-vanadium steel
Basic body surface: chrome-plated, matt satin finish

Notice

This special tool may only be subjected to the maximum torque. For this reason, the wrenches are only suitable for loosening bolts to a limited extent.

Products specifications

Width across flats (SW)	21 mm
Thickness of jaw (a1)	13 mm
Width of jaws (outside) (b1)	45.8 mm
Ring thickness (a2)	9 mm
External diameter of ring (d)	40 mm
Max. torque (F max.)	330 Nm
Length (l)	289 mm

Würth Catalogue(2)

Catalogue page as PDF 1

Flip catalog

Products specifications

Width across flats (SW)	21 mm
Thickness of jaw (a1)	13 mm
Width of jaws (outside) (b1)	45.8 mm
Ring thickness (a2)	9 mm
External diameter of ring (d)	40 mm
Max. torque (F max.)	330 Nm
Length (l)	289 mm
