Door closer STS 281 with scissor arm - DRCLSR-COMPAARM-STS281-SILVER

Door closer STS 281 with scissor arm

Article No. 0688001286

Door closer STS 281 with compass arm DRCLSR-COMPAARM-STS281-SILVER

€41.30 inc. VAT price per 1 PCS

Available on Order
Price may vary

Packaging Unit *

Qty:

+ -

Direct mounting without the need for a mounting plate

Hydraulic top door closer with controlled closing sequence.
Precise controlling of the closing speed and end stop via a hexagon socket screw from the side
Aluminium body and aluminium front slide cap
Slim design
Can be adapted to local circumstances

Notice

The closing force can be changed by changing the installation position.

This means the versatile door closer can be used on doors of different weights and sizes.

If door closers are mounted in damp rooms, unprotected outdoor installations, or for use in environments with aggressive, corrosive air content, special versions or protective measures are required.

Application area

Hinge side normal assembly DIN L (DIN R mirror-image)

Non-hinge side head assembly DIN R (DIN L mirror-image)

Specified dimensions not binding. Subject to technical changes.

Specification
Technical Information
Documents

Direct mounting without the need for a mounting plate

Hydraulic top door closer with controlled closing sequence.
Precise controlling of the closing speed and end stop via a hexagon socket screw from the side
Aluminium body and aluminium front slide cap
Slim design
Can be adapted to local circumstances

Notice

The closing force can be changed by changing the installation position.

This means the versatile door closer can be used on doors of different weights and sizes.

If door closers are mounted in damp rooms, unprotected outdoor installations, or for use in environments with aggressive, corrosive air content, special versions or protective measures are required.

Application area

Hinge side normal assembly DIN L (DIN R mirror-image)

Non-hinge side head assembly DIN R (DIN L mirror-image)

Specified dimensions not binding. Subject to technical changes.

Products specifications

Area of application	Object area<br>Private area
Suitable for	Interior doors<br>House doors<br>Toilet and bathroom doors<br>Apartment entrance doors<br>Profiled frame doors<br>Tubular door frames
Suitable for number of doors	1
Fire protection certified	No
Suitable for barrier-free construction according to DIN 18040	No
Suitable for min./max. door width	750-1100 mm
Suitable for min./max. door thickness	35-120 mm
DIN direction	DIN R/L
Mounting option	Hinge side: standard mounting<br>Opposite hinge side: head mounting<br>Direct mounting
Colour	White aluminium RAL 9006
Min./max. door closer size	1-4
Material	Aluminium / plastic / steel
Surface	Lacquered
Opening angle hinge side	180 Degree
Opening angle opposite hinge side	170 Degree
Closing speed	Infinitely adjustable by valve 170° - 0 ° opposite hinge side head assembly<br>Infinitely adjustable by valve 180 ° - 0° hinge side normal assembly
Back-check action	No
Latching speed	Infinitely adjustable by valve 10° - 0 °
Min./max. temperature conditions	-15 to 40 °C
Standards	DIN 1154
EC declaration of conformity (CE)	No
Environmental Product Declaration	Yes
