Ratchet combination wrench, metric, straight

Article No. 071425108

Ratchet combination wrench, metric, straight RTCHCOMBIWRNCH-WS8 ZEBRA

€23.97 inc. VAT price per 1 PCS

LOW STOCK

Packaging Unit *

Qty:

+ -

Drive: Modified POWERDRIV bi-hexagon ring end, finely toothed, 72 teeth
Standard: max. torque according to DIN 899
Geometry: Straight ring end, jaw angle 15°
Loosen bolts with the open end and tighten with the ratchet mechanism of the ring end
Ultra slim ring end for working in tight spaces, 5° angle of rotation, precision-manufactured ring core for smooth, secure movement
Material: Chromium-vanadium steel
Basic body surface: chrome-plated, matt satin finish

Notice

This special tool may only be subjected to the maximum torque. For this reason, the wrenches are only suitable for loosening bolts to a limited extent.

Specification
Technical Information
Documents

Drive: Modified POWERDRIV bi-hexagon ring end, finely toothed, 72 teeth
Standard: max. torque according to DIN 899
Geometry: Straight ring end, jaw angle 15°
Loosen bolts with the open end and tighten with the ratchet mechanism of the ring end
Ultra slim ring end for working in tight spaces, 5° angle of rotation, precision-manufactured ring core for smooth, secure movement
Material: Chromium-vanadium steel
Basic body surface: chrome-plated, matt satin finish

Notice

This special tool may only be subjected to the maximum torque. For this reason, the wrenches are only suitable for loosening bolts to a limited extent.

Products specifications

Width across flats (SW)	8 mm
Thickness of jaw (a1)	6.6 mm
Width of jaws (outside) (b1)	16.7 mm
Ring thickness (a2)	4.4 mm
External diameter of ring (d)	16 mm
Max. torque (F max.)	34 Nm
Length (l)	140 mm

Würth Catalogue(2)

Catalogue page as PDF 1

Flip catalog

Products specifications

Width across flats (SW)	8 mm
Thickness of jaw (a1)	6.6 mm
Width of jaws (outside) (b1)	16.7 mm
Ring thickness (a2)	4.4 mm
External diameter of ring (d)	16 mm
Max. torque (F max.)	34 Nm
Length (l)	140 mm
