Lining tape

Article No. 087571205

Lining tape GLAZMNTTPE-SA-GREY-12X5MM-10M

€2.95 inc. VAT price per 10 PCS

AVAILABLE

Packaging Unit *

Qty:

+ -

For glazing on windows, doors and fixed glazing

Can be compressed
Prevents three-point adhesion
Fills rebate for glazing, reducing the sealant consumption
Acts as movement damping section with heavy exposure to winds
Very fine, uniform, completely closed cell structure
Decorative, smooth surface
Highly elastic
High mechanical values with low volume weight
Excellent resistance to chemicals
Highly resistant to weathering
Excellent thermal insulation values
Storage: 12 months if stored in a cool, dry place
Excellent resistance to UV
Compatible with acrylic glass

Notice

Without cover film

The usage instructions are recommendations based on the tests we have conducted and based on our experience; carry out your own tests before each application. Due to the large number of applications and storage and processing conditions, we do not assume any liability for a specific application result. Insofar as our free customer service provides technical information or acts as an advisory service, no responsibility is assumed by this service except where the advice or information given falls within the scope of our specified, contractually agreed service or the advisor was acting deliberately. We guarantee consistent quality of our products. We reserve the right to make technical changes and further develop products.

Specification
Application
Technical Information
Documents

For glazing on windows, doors and fixed glazing

Can be compressed
Prevents three-point adhesion
Fills rebate for glazing, reducing the sealant consumption
Acts as movement damping section with heavy exposure to winds
Very fine, uniform, completely closed cell structure
Decorative, smooth surface
Highly elastic
High mechanical values with low volume weight
Excellent resistance to chemicals
Highly resistant to weathering
Excellent thermal insulation values
Storage: 12 months if stored in a cool, dry place
Excellent resistance to UV
Compatible with acrylic glass

Notice

Without cover film

Instructions

The processing temperature should not be below +5°C.

The surface must be dry and free from dust, oil and grease.

The lining tape should be used in connection with an edge sealant.

Products specifications

Chemical basis	Closed-cell polyethylene foam
Colour	Grey
Total thickness	5 mm
Min. tensile strength	0.325 N/mm²
Min. transverse tensile strength	0.220 N/mm²
Conditions for tensile strength	in accordance with ISO 1926
Moulded density	29 kg/m³
Compression force deflection	98 kPa
Compression force deflection conditions	in accordance with ISO 844, 50% deformation
Min. breaking elongation	125 %
Min. diagonal breaking elongation	115 %
Water-vapour permeability	0.72 g/m²/d
Conditions for water-vapour permeability	in accordance with ISO 1663, specimen thickness 5 mm
Heat conductance λ	0.034 W/(m*K)
Heat conductance λ conditions	at 0°C, in accordance with ISO 2581
Width	12 mm
Building material class	B3 - Of high flammability
Building material class conditions	in accordance with DIN 4102
Ultraviolet resistance	Yes
Min. processing temperature	5 °C
Max. processing temperature	25 °C
Min. temperature resistance	-30 °C
Max. temperature resistance	80 °C
Shelf life from production	12 Month
Conditions to maintain shelf life from production	cool and dry storage area
Length of roll	10 m
